5kVA Pole Mounted Transformer Low Loss All Weather Outdoor Pad Mounted Transformer
| MOQ: | 1unit |
| Price: | $1000-$10000 |
| Standard Packaging: | 1000set/month |
| Delivery Period: | 30days |
| Payment Method: | T/T |
| Supply Capacity: | Plywood case |
5kva pole mounted transformer
,pole mounted transformer low loss
Reliable 5kVA Pole Transformer 4.16kV/120V, Low Loss & All-Weather Outdoor Operation
Reliable 5kVA Pole Transformer 4.16kV/120V | Leilang Electric
Low Loss & All-Weather Outdoor Operation
Product Overview
The Leilang Electric 5kVA single-phase pole mounted transformer is engineered for dependable 4.16kV to 120V voltage conversion, delivering consistent power for residential, rural, and light commercial overhead distribution systems. Built with premium low-loss magnetic circuit and winding design, this unit minimizes energy waste while maintaining stable output under fluctuating loads. Featuring a rugged all-weather enclosure, corrosion-resistant tank, and fully sealed oil-immersed structure, it operates reliably in rain, wind, humidity, high temperature, and coastal environments year-round. Combining proven reliability, industry-standard voltage matching, ultra-low operating loss, and outdoor durability, this Leilang 5kVA pole transformer provides a cost-effective, low-maintenance solution for utility grids, street lighting, farms, and remote power supply projects.
Core Structure & Process Advantages
All-Weather Sealed Cylindrical Tank
Constructed with heavy-duty cold-rolled steel and electrostatic anti-corrosion coating, the tank withstands UV, rain, salt spray, and extreme temperatures. Fully sealed vacuum oil filling blocks moisture and dust, preventing insulation aging and ensuring long-term outdoor stability. Integrated cooling fins maintain optimal temperature for continuous operation.
Low-Loss High-Efficiency Core
Adopts high-permeability cold-rolled oriented silicon steel with precision step-lapped lamination to drastically reduce no-load and load losses. This low-loss design boosts energy efficiency, lowers long-term power costs, and complies with global energy-saving standards. Vacuum impregnation enhances mechanical strength and reduces operating noise.
Stable Winding & Insulation System
High-conductivity copper windings ensure low resistance and strong short-circuit withstand capability. Insulation materials undergo vacuum pressure impregnation (VPI) for superior dielectric strength and lightning impulse resistance. High-creepage bushings resist pollution and rain flashover for reliable performance in harsh outdoor conditions.
Quick Pole-Mount Installation
Designed for direct mounting on standard utility poles with universal brackets, enabling fast on-site wiring and commissioning without ground construction. Built-in pressure relief valve, oil level indicator, and safety protection devices support maintenance-free daily operation.
Core Technical Specifications
10kVA-500kVA Single-phase oil immersed transformer
| 10kva-500kva Single-phase oil immersed transformer | ||||||
| Rated Cap acity(kVA) | High | Low Voltage(v) | Connection Symbol | Standard | Short-circuit impedance(%) | Efficiency |
|---|---|---|---|---|---|---|
| Voltage(v) | (%) | |||||
| 10 | 4160 7200 12000 12470 13200 13800 19920 24940 34500 |
110 220 230 400 480 |
II0,II6 | IEEE/ANSI/ DOE/CSA | 1.0-4.5% | 98.7 |
| 15 | 98.82 | |||||
| 25 | 98.95 | |||||
| 37.5 | 99.05 | |||||
| 50 | 99.11 | |||||
| 75 | 99.19 | |||||
| 100 | 99.25 | |||||
| 167 | 99.33 | |||||
| 250 | 99.39 | |||||
| 333 | 99.43 | |||||
| 500 | 99.49 | |||||
Core Performance Highlights
- Leilang Reliable Performance - Strict quality control and field-proven design ensure stable, uninterrupted operation.
- 5kVA 4.16kV/120V Standard Matching - Perfect voltage ratio for North American-style single-phase distribution.
- Low Loss & Energy Saving - Optimized magnetic circuit cuts power loss and reduces operational expenses.
- All-Weather Outdoor Durability - Corrosion-proof, sealed, and weather-resistant for year-round outdoor service.
- Fast Pole Installation - Compact, lightweight, and easy to mount with minimal labor and no land occupation.
Application Scenarios
- Rural power grid renovation and remote residential power supply
- Street lighting, landscape power, and community low-voltage distribution
- Agricultural irrigation, farms, and small livestock facilities
- Small shops, temporary construction power, and communication base stations
- Coastal, high-humidity, and high-temperature outdoor power scenarios
Quality Assurance & Service
Leilang Electric manufactures under ISO 9001 quality management system. Each transformer passes routine test, withstand voltage test, and type test before shipment. We provide customized voltage, full technical documentation, and after-sales support to ensure stable performance throughout the product lifecycle.
Frequently Asked Questions
1. Is this 5kVA pole transformer suitable for all-weather outdoor use?
Yes. The Leilang 5kVA unit features a fully sealed, corrosion-resistant tank and weatherproof components, operating reliably in rain, wind, salt spray, humidity, and temperatures from -40°C to +55°C.
2. What are the input and output voltages of this transformer?
It is designed for 4.16kV primary input and 120V secondary output, ideal for standard single-phase distribution systems.
3. Does this Leilang transformer feature low loss design?
Absolutely. It uses high-grade low-loss silicon steel core and optimized winding structure, achieving high efficiency up to 98.5% and significantly reducing energy consumption.
4. How reliable is this 5kVA pole mounted transformer?
Produced by Leilang Electric with strict quality inspection, it offers stable voltage regulation, strong overload capability, and long service life for continuous grid operation.
5. Can it be installed directly on a utility pole?
Yes. It adopts a compact pole-mounted design with standard mounting brackets for quick, space-saving installation without ground construction.
6. What applications is this transformer mainly used for?
It is widely used in rural grids, residential areas, street lighting, farms, small businesses, and various outdoor and remote power supply scenarios.
7. Does it require frequent maintenance?
The fully sealed structure minimizes oil oxidation and insulation aging, supporting long-term maintenance-free operation with only regular visual inspection needed.
8. Can voltage be customized for specific projects?
Yes, Leilang Electric supports custom primary/secondary voltages such as 120/240V split-phase to meet local utility requirements.
