4160GrdY 100 Kva Pad Mount Transformer 4.16kV To 120V Single Phase Transformer
| MOQ: | 1unit |
| Price: | $1000-$10000 |
| Standard Packaging: | 1000set/month |
| Delivery Period: | 30days |
| Payment Method: | T/T |
| Supply Capacity: | Plywood case |
4160GrdY 100 kva pad mount transformer
,100 kva pad mount transformer 4.16kV
,120V single phase transformer pad
Leilang Electric's 100kVA single phase pole mounted transformer is professionally engineered for reliable 4.16kV to 120V voltage conversion, featuring two core competitive advantages: UL certification and high efficiency. Fully compliant with UL Subject 8750 safety standards, as well as ANSI, IEEE, IEC, and DOE energy efficiency requirements, it meets strict reliability criteria for North American residential, commercial, and light industrial overhead power distribution scenarios.
With official UL certification, it ensures full compliance with U.S. electrical safety regulations, enabling direct grid connection without additional modifications. Its optimized high-efficiency design, featuring a low-loss core and precision windings, achieves an efficiency rating of up to 99.25%, significantly reducing energy waste and long-term operating costs while aligning with global carbon neutrality goals.
Strictly manufactured in accordance with UL Subject 8750 safety standards, this transformer undergoes rigorous testing to ensure compliance with U.S. electrical safety regulations. It features a fully sealed oil-immersed tank with seamless welding and vacuum oil filling, preventing moisture, dust, and air ingress to avoid insulation failure and safety hazards.
High-creepage polymer bushings with anti-pollution and anti-rain flashover design enhance insulation reliability, while built-in current-limiting fuses and pressure relief valves provide additional safety protection. The transformer also incorporates a ground shielding design to reduce electromagnetic interference, further improving operational safety.
Adopts high-quality cold-rolled oriented silicon steel core with step-lapped lamination technology, minimizing hysteresis and eddy current losses. Windings are made of high-conductivity oxygen-free copper, processed with vacuum pressure impregnation (VPI) to reduce resistance loss and improve energy transfer efficiency.
This design not only achieves an efficiency rating of up to 99.25% but also complies with the latest DOE energy efficiency standards and GB 20052-2024 energy efficiency requirements, reducing long-term electricity costs for users and supporting energy-saving initiatives.
Optimized winding turns ratio and precision winding process ensure accurate voltage conversion from 4.16kV high voltage to 120V low voltage, with excellent load regulation performance. Even under fluctuating loads, it maintains stable output voltage, avoiding voltage surges or drops that damage electrical equipment.
Designed with 100kVA rated capacity, it is suitable for large-scale single-phase distribution scenarios, capable of supporting continuous operation of multiple electrical devices. It has strong overload capacity, able to withstand 120%-150% short-term load impact while maintaining stable efficiency and voltage output.
Designed for direct mounting on standard utility poles, with pre-installed brackets and clearly labeled terminals for quick on-site installation. The compact structure saves space, requires no large-scale civil engineering, and is suitable for various distribution network scenarios.
| Item | Value |
|---|---|
| Rated Capacity | 100kVA |
| High Voltage | 4160V |
| Low Voltage | 120V (customizable to 120/240V split-phase) |
| Efficiency | ≥99.25% |
| Cooling Type | ONAN (Oil-Immersed Self-Cooled) |
| Operating Temp Range | -40°C ~ +55°C |
| Certification | UL, ANSI, IEEE, IEC, DOE |
| Short-Circuit Impedance | 1.0-4.5% |
| Rated Capacity (kVA) |
High voltage (kV) |
No Load Loss (W) |
On load Loss (W) |
Height (mm) |
Depth (mm) |
Width (mm) |
Weight (kg) |
| 15 kVA | 34.5/19.92 13.8/7.96 13.2/7.6 12.47/7.2 or others |
50 | 195 | 840 | 740 | 610 | 294 |
| 25 kVA | 80 | 290 | 840 | 740 | 610 | 362 | |
| 37.5 kVA | 106 | 360 | 840 | 760 | 610 | 476 | |
| 50 kVA | 135 | 500 | 840 | 810 | 610 | 553 | |
| 75 kVA | 190 | 650 | 840 | 860 | 610 | 672 | |
| 100 kVA | 280 | 1010 | 910 | 1200 | 965 | 714 | |
| 167kVA | 435 | 1530 | 1000 | 1200 | 965 | 913 | |
| 250 kVA | 550 | 2230 | 1250 | 1300 | 1430 | 1106 |
- UL Certified - Fully compliant with UL Subject 8750 safety standards, meeting U.S. electrical regulatory requirements for direct grid connection and safe operation.
- High Efficiency (≥99.25%) - Low-loss core and copper winding design reduce energy waste, lower long-term operating costs, and comply with global energy-saving goals.
- 100kVA Stable Capacity - Ideal for large-scale single-phase distribution, supporting continuous operation with strong overload capability.
- Precise 4.16kV/120V Conversion - Stable voltage output with excellent load regulation, protecting connected electrical equipment.
- Durable & Easy Installation - Fully sealed oil-immersed structure for outdoor durability, with standard pole-mounted design for quick installation.
- Large residential communities, high-rise buildings, and villa districts requiring stable, efficient, and UL-compliant power supply
- Commercial complexes, shopping malls, office parks, and retail centers with large-scale single-phase power demand
- Light industrial facilities, manufacturing workshops, and small factories requiring reliable 4.16kV/120V voltage conversion
- Urban, suburban, and rural single-phase power distribution networks, including street lighting and public facility power systems
- North American projects requiring UL certification, such as utility grid upgrades and new community construction
This transformer is produced under the ISO 9001 quality management system, with each unit undergoing strict factory testing (no-load test, load test, withstand voltage test, insulation test, and UL certification test) before delivery. It fully meets the requirements of GB 20052-2024 and other energy efficiency standards.
We provide customized voltage configurations (such as 120/240V split-phase) and accessory options, along with complete UL certification documents and professional technical support. Our 24-hour after-sales service and spare parts supply ensure stable operation throughout the product's long service life.
